Still unsure on what bike frame to get? Check out our recommended size guide or contact us via live chat or 1300 310 493 number to talk to our friendly staff for the best option.
*Images provided are for reference only. Actual product may vary. Please note - Due to supplier shortages, we may supply you a product or its components from an equivalent or greater brand. For more details please contact us.
This product requires assembly
We provide easy step by step instructions & supporting video tutorials to help you with assembly & adjustments. If you are unfamiliar with assembling or adjusting Bicycles or Tricycles, or find it difficult to assemble or adjust with the instructions supplied, we strongly recommend that this product is built by an experienced bike mechanic. Any damage resulting from improper assembly will not be covered by warranty. See Assembly details
Please see below for all Click & Collect locations. Place an order online, get notified and pick up the order at your convenience.
Broadmeadows, VIC
Willawong, QLD *Pre-Booked Pick Ups Only
Click here for more details on Click & Collect and Pick Up
Bike Size Guide
YOU MIGHT WANT TO ADD
How Progear Works
Order Online
Click & Collect
Easy Assemble
Video instructions included
Done!
Ride your new bike!
Chrome Hi-Ten Steel Frame
classic 26" tyres
BMX Style Handlebars
Classic Plastic Black Saddle
Chrome Hi-Ten Steel Frame
Our Chrome plated Hi-Tensile Steel Frame is a real head turner and built to last.
Stopping Power
Stop on a dime with safe and reliable front and rear V-brakes.
Single Speed
Our BMX bikes not only look cool, but are incredibly easy to maintain; they come with minimal components and gives you complete control & handling of the bike.
26" Tyres
26" tyres have always been the traditional tyre for BMX racing, so it would be appropriate that our Classic BMX comes with its classic 26" tyres.
Top Load Stem
Top Load Stems absorb impact better than other stems making some floor tricks such as Hops easier to execute. You’ll also get a higher handlebar rise and increased durability with our Alloy top load stem.
The Blueprints
An awesome package with the following components:
The Blueprints
An awesome package with the following components:
A. BMX Style Handlebars
B. Classic Plastic Black
C. Rear Alloy V-Brake
D. Classic 26" Tyres
E. Top Load Stem
F. Chrome Hi-Ten Steel Frame
G. Front Alloy V-Brake
Where to ride?
Where to ride?
Specification
Technical Specifications
Frame Sizes
17"
Frame
Steel 26"x 432mm
Fork
26”x143mm
Handlebars
W:720mm,H:190mm,7°, cross bar:22.2x281mm
Grips
Rubber 125mm
Stem
Alloy 22.2,L:150mm
Seatpost
25.4x300mm
Seat Clamp
28.6mm?alloy black
Saddle
Classic Plastic Black
Pedals
1/2" Black
Front Brakes
Alloy V-Brake
Rear Brakes
Alloy V-Brake
Brake Levers
Alloy black clamp/silver lever
Freewheel
18t
Chainwheel & Cranks
44T Silver Chainwheel. 170mm Crank
Chain
100L
Chainguard
Clear
Bottom Bracket
Steel GS-B909
Headset
22.2
Front Hub
14GX36Hx100x160mmx(3/8'')?alloy black
Rear Hub
14Gx36Hx1SPDx110x155x(3/8”)?alloy black
Spokes
14G steel UCP , L:262mm, L:263mm, with copper cap
Tyre
26”x2.125” , Black
Tube
26”x2.125”A/V
Rim
26”x1.75x36Hx14G,A/V
Bell
Included
Box Sizing Guide
Frame Size Number
One Size
Wheel Size
26"
Suggested Height
165-185cm
Minimum Suggested Inseam
74cm
A - Seat Tube
43.2cm
B - Seat Tube Angle
72deg
C - Head Tube Length
11cm
D - Effective Top Tube
58.5cm
E - Chainstay length
43cm
F - Wheelbase
104cm
G - Standover
71cm
HOW TO MEASURE YOUR INSEAM FOR BIKE
1 Stand straight with your back against the wall and feet shoulder-width apart.
2 Place a book between your legs and raise as far as possible, this imitates a seated bike position.
3 Use a measuring device to measure from the top of the book to the floor (in cm). This measurement is your inseam length.
*Images provided are for reference only. Actual product may vary. Please note - Due to supplier shortages, we may supply you a product or its components from an equivalent or greater brand. For more details please contact us.
Warranty
Lifetime warranty on Frame and Fork
12 Months Manufacturer's Warranty on all non-consumable components
12 Months Manufacturer's Warranty on all electrical components, such as motors, display or batteries.
Consumable parts (including grips, tubes, tyres, cables, brake pads, saddle coverings, chain, spokes, cassettes and chain rings) are not covered by the warranty.
